Portable XRF Metal Components Analyzer

SciAps X-50 Portable XRF Analyzer"Classical" model delivers excellent data for a wide range of applications The SciAps X-50 is a high-performance portable XRF analyzer redesigned with the latest technology and equipped with a cost-effective Silicon Drift Detector (SDD). Fast and precise analysis is possible thanks to the powerful miniature X-ray tube and advanced interior design that operates at more than twice the speed of other brands.Key feature analysis targets: Optimized for basic analysis of transition metals and heavy metals X-ray Tube:40 kV Rh anode (for alloys) or 50 kV Au anode (for geochem, Soil, etc.) Detector: 7 mm² Silicon Drift Detector (SDD), 170 eV resolution FWHM at Mn K-alpha line (5.95 keV) Integrated camera: High resolution sample viewer and macro camera, photographic recording and 2D/3D barcode recognition and storable weight: Approximately 1.4 kg (3.1 lbs) with battery: 238 mm size, In-device and external charging, hot-swap support (up to 60 seconds replacement time) Display: 3.5-inch color touchscreen communication: WiFi, Bluetooth, USB support Security: User and administrator level password protection feature specification certification: CE, RoHS, USFDA registration, Canadian RED compliance Standard Element Package (analyzable element package) ApplicationBeam 1 (40 kV)MinningTi, V, Cr, Mn, Fe, Co, Ni, Zn, As, Se, Sr, Rb, Zr, Nb, Mo, W, Ta, Au, Sb<br>SoilTi, V, Cr, Mn, Fe, Co, Ni, Cu, Zn, As, Se, Sr, Rb, Zr, Mo, W, Tl, Hg, Pb, Bi, Ag, Cd, Sn, Sb<br>AlloyTi, V, Cr, Mn, Fe, Co, Ni, Cu, Zn, Se, Y, Zr, Nb, Mo, W, Ta, Hf, Re, Au, Pb, Bi, Ru, Pd, Ag, Cd, Sn, Sb<br>Precious MetalsTi, Cr, Mn, Fe, Co, Ni, Cu, Zn, Ga, W, Au, Ge, Ir, Pt, Pb, Bi, Zr, Mo, Ru, Rh, Pd, Ag, Cd, In, Sn, Sb<br><br>필요 시 별도 원소 추가 및 교체 가능주요 사양 (Key Specifications)Processor:1.2 GHz quad ARM Cortex A53 64/32-bitRAM:2 GB LP-DDR3Storage:16 GB eMMCDisplay:3.5-inch color capacitive touchscreenPulse Processor:12 bit digitization rate of 80 MSPS, 8K channel MCA, FPGA-based digital filteringConnectivity:WiFi, Bluetooth, USBCalibration: Fundamental parameters-based automatic calibration check: Calibration and energy scale with external 316 stainless steel standards X-ray filtering: Single filters for alloys, mining, precious metals / Soil, RoHS, Multiple filters for automotive catalysts Operating Temperature: 10°F to 130°F (approximately -12°C to 54°C), 25% duty cyclePower: Built-in Li-ion battery, hot-swap support, AC-powered SciAps X-50 silver provides high performance and fast analytical speed in various applications such as scraps, alloys, and geology.Inquiries and requests for quotes are welcome at any time
