Metkon MOBIPREP & MOBISCOPE Portable metal biopsy solution MOBIPREP - Portable polishing and corrosion device Battery drive: Can be used in the field without power Precision hand guide device: High performance micro-motor, 45°/90°/straight angle selection Enhance portability: Hard case and bag corrosion (etching) Function: Electrolytic corrosion pen available → On-site alloy steel corrosion resolution with weak electrolyte instead of strong acid Suitable for non-destructive testing: Large structure and facility on-site analysis Specification output: 36V, 5-step adjustment speed: 0.25,000 rpm Disc Diameter: Ø 30 mm Size: 104 × 54 × 160 mm Weight: 1 kgMOBISCOPE - Portable Metal Microscope: Field tissue observation available Magnification magnification: 100×500× (10×, 50× Object lens standard / 20×, 80× Option) Magnetic Stage: Fixed anywhere flat or curved Light Source: Built-in rechargeable LED lighting (No power required) Portable case: Aluminum transport case Specification eyepiece: WF10X (FN18) Object lens: 10x/0.25 (WD 7.3 mm), 50x/0.65 (WD 0.5 mm) Focus, C-mount Camera Connectivity Key applications Power plants, storage tanks, piping systems On-site inspection of purchase parts Quality management (QA/QC) Utilization of non-destructive Replica techniques (flat and curved) Metallic tissue change assessment over the life cycleInquiries and quotes are welcome at any time.
